• Skid Steer Power Required: 30–60 HP
• Mount Type: Universal skid steer mount
• Hydraulic Flow Rate: 19–26 L/min
• Hydraulic Pressure: 16 MPa
• Hydraulic Hoses & Flat Face Couplers: Included
• Hydraulic Flat Face Couplers Spec: 1/2"
• Number of Hydraulic Hoses: 2
• Hydraulic Hoses Diameter: DN13
• Bucket Rotation Degree: 180°
• Swing Arc: 180°
• Max. Digging Depth: 2340 mm (7'8")
• Max. Working Height: 2845 mm (112")
• Max. Working Length: 3000 mm (118")
• Max. Loading Height: 1830 mm (72")
• Stabilizer Width (Spread): 2360 mm (89")
• Stabilizer Width (Transport): 1650 mm (58")
• Ground Clearance: 250–305 mm (10"–12")
• Bucket Size: 305 mm (12")
• Bucket Capacity: 0.028 m³ (1 cu-ft)
• Dipper Boom Digging Force: 930 kg (2050 lb)
• Bucket Digging Force: 1440 kg (3180 lb)
• Bucket and Boom Dig Simultaneously: Yes
• Surface Finish: Powder coating
• Overall Dimensions: 2260 × 1650 × 1520 mm (89" × 65" × 60")
• Net Weight: 517 kg (1140 lb)

The order will ship from one of our warehouses in Australia. Under normal circumstances, it will take 2 to 3 business days to process and dispatch your order. Delivery typically takes 10 to 15 business days depending on your location and accessibility.

• This product is packed in a metal crate shipping box
• Shipping dimensions: 191 × 74 × 125 cm (W × L × H) / 75" × 29" × 49"
• Shipping weight: 601 kg (1325 lb)

We know that when you invest in equipment, you're counting on it to perform day in and day out. At TMG Industrial, that trust means everything to us. That’s why we include a 1-year Warranty with every product we sell—because you deserve confidence with every purchase.

Our warranty is there to make sure your equipment stays reliable across the seasons, covering any issues caused by manufacturing defects in materials or workmanship. From fieldwork to property maintenance, you can count on your TMG equipment to deliver.

More than just warranty coverage, we’re committed to supporting you throughout the life of your machine. Our customer service team is here to help, whether you need technical advice, troubleshooting, or parts support.

For full warranty terms, please see our warranty policy

• Q: What is the grappling capacity of the TMG-SG42?
  A: It provides a reliable capacity of 900 kg (2000 lb), suitable for challenging material handling across multiple industries.
• Q: What are its key operational dimensions?
  A: Measures 1070 mm (42") in working width, with an arm opening of 610 mm (24").
• Q: What hydraulic pressure is required and is the cylinder protected?
  A: Operates at 20 MPa (3000 PSI) and includes a protective guard to shield the hydraulic cylinder from impact and debris.
• Q: How easy is maintenance on the TMG-SG42?
  A: The unit is designed for ease of maintenance, featuring greaseable pins and bushings that promote longevity and minimal upkeep.
• Q: What hardware comes included for installation?
  A: It includes a Toro style mount, hydraulic hoses, and flat face couplers for quick, secure integration with your skid steer.
• Q: What design features enhance debris handling?
  A: The skeleton tine bottom allows fine debris to fall through, enabling focused handling and efficient cleanup of larger materials.
• Q: What is the warranty for TMG-SG42?
  A: It is backed by a 1-year manufacturer warranty covering defects in materials and workmanship. Customer support and spare parts are also available.
